Product Description & Specifications
Confirm the complete catalog number and application requirements before ordering. The specifications below reflect the product information available for this listing.
- Manufacturer
- Schneider Electric
- Brand
- Square D
- Sub-Category
- Parts & Accessories
- Frame
- Homeline
- Rated current
- 125
- Voltage
- 120/240VAC
- Poles
- 2
- Standards
- RoHS
- Country of origin
- Mexico
- Compatible Frames
- HOM
- UPC
- 785901065920
- GTIN
- 00785901065920
- Dimensions
- Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
- Weight
- 0.74
Show all specifications (1 more)
- Certification
- UL LISTED
Product description & additional details
HOML2125
HOML2125 is a Square D 2 pole lug kit designed for Homeline load centers with a 125 ampere current rating and 120/240VAC voltage rating.This lug kit features a HOM frame type and is used for subfeed applications, providing a reliable and field-installable solution for connecting to another panel or device. It supports wire sizes from AWG 1 up to 300 kcmil and complies with RoHS standards.
- Manufacturer: Square D
- Amperage: 125A
- Voltage: 120/240VAC
- Poles: 2
- Frame Type: HOM
- Mounting Type: Plug-on for Homeline Load Centers
- Max Wire Size: 300 kcmil
- Min Wire Size: AWG 1
- Standards: RoHS Compliant
- Application: Subfeed Lug Kit
- Compatible with Homeline Series
Specifications
- Part Number: HOML2125
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Parts & Accessories
- Type : Homeline
- Voltage : 120/240VAC
- Amperage : 125
- Poles : 2
- Compatible Frames : HOM
Product Data
- UPC : 785901065920
- GTIN : 00785901065920
- Country of Origin : Mexico
- Dimensions : Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
- Weight : 0.74
- Standards : RoHS
- Certification : UL LISTED
