Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
HNXD63B800
HNXD63B800 is a 3-pole, 600-volt, 800-ampere bolt-on molded case circuit breaker from Siemens Sentron Series with high interrupting capacity rated at 65 kiloamperes at 480 volts and 25 kiloamperes at 600 volts. This thermal magnetic circuit breaker features a non-interchangeable trip unit and is designed for industrial and commercial power distribution applications requiring reliable overcurrent protection. The breaker meets UL 489 and IEC 60947-2 standards and operates at standard 40-degree Celsius rating with load-side lug terminals for secure connections.
- Amperage Rating: 800A
- Voltage Rating: 600VAC
- Number of Poles: 3
- Mounting Type: Bolt-On
- Series: Sentron HNXD
- Interrupting Rating: 65kA at 480V, 25kA at 600V
- Trip Unit: Non-Interchangeable Thermal Magnetic
- Certifications: UL 489, IEC 60947-2
- Temperature Rating: 40 Degrees Celsius
- Terminals: Load-Side Lugs
Specifications
- Part Number: HNXD63B800
- Manufacturer : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : HNXD
- Voltage : 600
- Amperage : 800
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : ND Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 65
