HNF361SS - Siemens 30 Amp 600V 3-Pole Heavy Duty Safety Switch Stainless Steel NEMA 4X

HNF361SS

HNF361SS is a Siemens heavy duty safety switch rated for 30 Amps and 600 Volts with a 3-pole configuration in a stainless steel enclosure.

This non-fusible safety switch features a 3-wire, 3-pole design with mechanical lug connections and a NEMA 4X (Type 4/4X) 316-grade stainless steel enclosure suitable for indoor and outdoor use. It has an interrupting rating of 200kA at 600V and is UL listed. The switch is surface mounted and designed for service entrance and load applications, providing reliable circuit protection and isolation.

• Manufacturer: Siemens
• Part Number: HNF361SS
• Amperage: 30 Amps
• Voltage Rating: 600 VAC
• Poles: 3
• Wires: 3
• Mounting Type: Surface Mount
• Interrupt Rating: 200kA @ 600V
• Frame/Series: HNF
• Trip Unit: Non-Fusible
• Enclosure: 316 Stainless Steel, NEMA 4X
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you (more...)

Specifications

• Part Number: HNF361SS
• Manufacturer : Siemens
• Brand : Siemens
• Category : Switch
• Item Subcategory : Disconnect
• Section : Non-Fusible Disconnect Switch
• Family : VBII Series
• Type : HNF
• Voltage : 600 AC AC
• Amperage : 30
• Phase : 3
• Poles : 3
• AIC rating : 200kA@600V
• Temp Rating : -13äóñ158 ŒÁF (-25äóñ70 ŒÁC)
• Configuration : Single
• Switch Style : Non-Fusible
• Nema Rating : NEMA 4X
• Compatible Frames : PGP

Product Data

• UPC : 040892169133
• GTIN : 0040892169133
• Country of Origin : Mexico
• Dimensions : 22.047 x 14.173 x 7.874 inch
• Weight : 23.656
• Temp Rating : -13äóñ158 ŒÁF (-25äóñ70 ŒÁC)
• Certification : UL listed
