Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
HND62F120
HND62F120 is a Siemens ND frame molded case circuit breaker rated for 1200 amperes at 600 VAC and 250 VDC with thermal magnetic trip protection. This 2-pole breaker delivers 25 kA interrupting capacity at 600 VAC and 50 kA at 480 VAC, meeting UL 489 and IEC 60947-2 standards for reliable industrial and commercial power distribution applications. The ND6 frame design provides standard breaking capacity with robust construction suitable for demanding electrical systems. Key Specifications
- Amperage: 1200 A
- Voltage: 600 VAC / 250 VDC
- Poles: 2
- Frame Type: ND6
- Interrupt Rating: 25 kA at 600 VAC, 50 kA at 480 VAC
- Trip Unit: Thermal Magnetic
- Certifications: UL 489, IEC 60947-2
- Manufacturer: Siemens
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
Specifications
- Part Number: HND62F120
- Manufacturer : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : HND
- Voltage : 600
- Amperage : 1200
- Phase : 1
- Poles : 2
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : ND Frame
- Protection : Thermal Magnetic
Product Data
- GTIN : 00783643215658
- Weight : 65
