HND62B120L - Siemens ND Frame 2-Pole 1200A 600V AC Molded Case Circuit Breaker 50kA Interrupt

HND62B120L

HND62B120L is a Siemens ND Frame molded case circuit breaker designed for reliable protection in industrial and commercial power distribution systems. This 2-pole, 1200A device features a 600V AC maximum voltage rating and a 50kA interrupt rating, making it suitable for demanding electrical environments. The breaker is equipped with a thermal magnetic trip unit for accurate overcurrent protection and is compatible with a wide range of accessories for flexible installation and monitoring. Its robust ND frame construction ensures durability and long-term performance. Siemens HND62B120L breakers are engineered for high in-rush current capability and include a push-to-trip button for easy operation. The breaker is designed for line/load lug connection and supports wire sizes from 250 to 500 kcmil. It is suitable for use in applications requiring 50/60 Hz frequency and is rated for 40°C ambient temperature. The breaker is HACR rated and meets applicable UL and CSA standards for safety and reliability.

• Part Number: HND62B120L
• Manufacturer: Siemens
• Frame: ND
• Number of Poles: 2
• Amperage Rating: 1200 A
• Voltage Rating AC: 600 V
• Interrupt Rating: 50 kA
• Frequency Rating: 50/60 Hz
• Temperature Rating: 40°C
• Connection Type: Line/Load Lug
• Wire Size: 250 to 500 kcmil
• Trip Unit: Thermal Magnetic
• Certifications: HACR, UL, CSA

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HND62B120L
• Manufacturer : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : HND
• Voltage : 600
• Amperage : 1200
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : ND Frame
• Protection : Thermal Magnetic

Product Data

• Weight : 65
