HMCPS030H1C - Cutler Hammer 30A 600V 3-Pole Motor Circuit Protector, Series C Frame J-K

HMCPS030H1C

HMCPS030H1C is a Cutler Hammer 3-pole motor circuit protector rated for 30 amperes and 600 volts, designed for panel mounting in industrial applications.This molded case circuit breaker from the Series C frame J-K offers magnetic-only trip protection with a trip range of 90-300A. It features feed-thru line and load side lug terminals, non-aluminum terminals, and complies with UL 489, CSA 22.2, and CE certifications. The breaker is suitable for motor protection with instantaneous magnetic trip and is rated for 600 VAC and 250 VDC maximum voltage.

Key Specifications
• Amperage: 30 A
• Voltage Rating: 600 VAC / 250 VDC
• Poles: 3
• Mounting Type: Panel Mount
• Interrupt Rating: Magnetic Trip, Instantaneous Protection Only
• Series/Frame: Series C, Frame J-K
• Terminal Material: Non-aluminum
• Trip Unit: Magnetic Only (90-300 A range)
• Certifications: UL Listed, CSA Certified, CE Approved
• Terminal Type: Feed-Thru Line and Load Side Lugs
• Weight: Approximately 4.5 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HMCPS030H1C
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HMCPS
• Voltage : 600
• Amperage : 30
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : I - Instantaneous
• Terminal Connection : Line/Load Lug
• Frame Size : 250A/J
• Temp Rating : Minimum Operating Temp -4 Degrees F Max. Operating Temp.158 Degrees F
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Magnetic Only
• Phase Connection : ABC

Product Data

• UPC : 786679232620
• GTIN : 00786679232620
• Country of Origin : Dominican Republic
• Dimensions : 8 in x 5 in x 5 in (Length/Depth x Height x Width)
• Weight : 4.5
• Panel Type : Motor Starters Equipped with Electronic Overload Relays
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
