- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
HMCPE100T3C
HMCPE100T3C is a 100 amp, 600 volt, 3-pole motor circuit protector from Cutler Hammer's Series C, Frame J-K line.This motor circuit protector features a magnetic trip range of 300-1000 A, non-aluminum terminals, and is designed for panel mounting. It complies with UL 489 standards and is UL Listed and CSA Certified, suitable for motor protection applications with adjustable full load current settings from 23.0 to 84.5 amps. The breaker supports a maximum voltage of 600 VAC and 250 VDC.
- Key Specifications
- Amperage: 100 A
- Voltage: 600 VAC / 250 VDC
- Poles: 3
- Frame: J-K
- Series: C
- Trip Unit: Magnetic trip range 300-1000 A
- Mounting Type: Panel mount
- Terminal Material: Non-aluminum
- Certifications: UL Listed, CSA Certified
- UL Standard: UL 489
- Motor Full Load Amps Adjustable: 23.0-84.5 A
- Weight: Approximately 4.5 lbs
- Part Number: HMCPE100T3C
- Manufacturer : Cutler Hammer
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series G
- Type : HMCPE
- Voltage : 480
- Amperage : 100
- Phase : 3
- Poles : 3
- AIC rating : 15kA@400V
- Connection : Feed-Thru
- Functions : Instantaneous
- Protection : Magnetic Only
- UPC : 786679113707
- GTIN : 00786679113707
- Country of Origin : Dominican Republic
- Dimensions : 6.5 in x 5.5 in x 3 in (Length/Depth x Height x Width)
- Weight : 3
- Certification : CSA Certified,UL Listed
