Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HMCPE030H1C
HMCPE030H1C is a 3-pole, 30 amp, 480 Volt circuit breaker designed for motor circuit protection with feed-thru mounting and HMCPE frame type.This molded case circuit breaker from NRI Industrial Sales LLC features a 3-pole design rated for 480V AC and 30 amps, suitable for motor circuit protection applications. It has a feed-thru mounting type and an interrupt rating of 15kA at 400V. The breaker is UL Listed and CSA Certified, with a NEMA 1 rating, ensuring compliance with industry safety standards.
- Key Specifications
- Manufacturer: NRI Industrial Sales LLC
- Part Number: HMCPE030H1C
- Amperage: 30A
- Voltage: 480V AC
- Poles: 3
- Mounting Type: Feed-Thru
- Frame Type: HMCPE
- Interrupt Rating: 15kA @ 400V
- Certifications: UL Listed, CSA Certified
- NEMA Rating: NEMA 1
Specifications
- Part Number: HMCPE030H1C
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series G
- Type : HMCPE
- Voltage : 480
- Amperage : 30
- Phase : 3
- Poles : 3
- AIC rating : 15kA@400V
- Connection : Feed-Thru
- Functions : I - Instantaneous
- Protection : Magnetic Only
Product Data
- UPC : 786679113660
- GTIN : 00786679113660
- Country of Origin : Dominican Republic
- Dimensions : 2.99 in x 5.5 in x 3 in (Length/Depth x Height x Width)
- Weight : 3 lb
- Certification : CSA Certified, IEC Rated, UL Listed
