HMCP600L6W - Cutler Hammer 600A 600V 3-Pole Molded Case Circuit Breaker Bolt-On Mount

HMCP600L6W

HMCP600L6W is a Cutler Hammer molded case circuit breaker designed for 600 amp, 600 volt applications with 3 poles and bolt-on mounting.This motor circuit protector from the Series C HMCP family features magnetic-only trip protection with instantaneous trip functions. It has an interrupt rating of 35kA at 480V and is built for reliable motor protection with a bolt-on connection type. The breaker frame is L frame type and it is suitable for 3-phase systems.

• Manufacturer: Cutler Hammer (Eaton)
• Part Number: HMCP600L6W
• Amperage: 600 A
• Voltage: 600 V AC / 250 V DC max
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 35kA @ 480V
• Series/Frame: Series C, L Frame
• Trip Unit: Magnetic Only, Instantaneous
• Phase: 3
• Dimensions: Approx. 10.75" H x 8.25" W x 4.06" D
• Weight: Approx. 20 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

Lugs are not included

Specifications

• Part Number: HMCP600L6W
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HMCP
• Voltage : 600
• Amperage : 600
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : I - Instantaneous
• Frame Size : L Frame
• Protection : Magnetic Only

Product Data

• UPC : 786679281369
• GTIN : 00786679281369
• Country of Origin : United States
• Dimensions : 4.06 in x 10.75 in x 8.25 in (Length/Depth x Height x Width)
• Weight : 20
• Certification : UL Listed,CSA Certified
