HMCP070J2C - Cutler Hammer 70 Amp 600VAC 3 Pole Motor Circuit Protector Panel Mount

HMCP070J2C

HMCP070J2C is a 70 Amp motor circuit protector from Cutler Hammer designed for panel mounting applications.This 3 pole molded case circuit breaker features a magnetic trip with fixed trip settings rated for 600 VAC and 250 VDC. It is part of the C Series frame and is motor rated for 115-170A with a starter size NEMA 2. The breaker provides UL, CSA, and CE approvals and is intended for industrial use without overload protection, requiring external motor starter heater overloads.

Key Specifications
• Manufacturer: Cutler Hammer (Eaton)
• Part Number: HMCP070J2C
• Amperage: 70 A
• Voltage Rating: 600 VAC, 250 VDC
• Poles: 3
• Mounting Type: Panel mount
• Trip Type: Magnetic fixed trip
• Motor Rating: 115-170 A
• Series/Frame: C Series
• Certifications: UL, CSA, CE
• Starter Size: NEMA 2
• Terminal Type: Line and load terminals
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: HMCP070J2C
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HMCP
• Voltage : 600
• Amperage : 70
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : I - Instantaneous
• Frame Size : F Frame
• Protection : Magnetic Only



Product Data

• UPC : 786679411919
• GTIN : 00786679411919
• Country of Origin : Dominican Republic
• Dimensions : 7.5 in x 5 in x 5 in (Length/Depth x Height x Width)
• Weight : 4.46
• Certification : CSA Certified,UL Listed
