HLDB3600C - Eaton Series C 600A 3-Pole Molded Case Circuit Breaker L-Frame 600V 100kAIC 240V 65kAIC 480V

HLDB3600C

HLDB3600C is a Series C complete molded case circuit breaker from Eaton, designed for reliable protection in demanding electrical environments. This L-frame breaker features a fixed thermal and fixed magnetic trip unit, providing robust overcurrent protection for three-phase systems. The HLDB3600C is built for durability and performance, with a robust aluminum terminal design and a compact footprint suitable for a wide range of industrial and commercial applications. This Eaton Series C circuit breaker is rated for 600A continuous current, 600 Vac, and 250 Vdc, with an interrupt rating of 100 kAIC at 240 Vac and 65 kAIC at 480 Vac. It is a three-pole device, compatible with standard L-frame mounting, and operates at 50/60 Hz. The breaker is UL Listed, ensuring compliance with recognized safety standards. The trip type is T186, and the terminals are designed for both line and load connections.

• Series: Series C
• Frame: L-Frame
• Amperage Rating: 600 A
• Voltage Rating: 600 Vac, 250 Vdc
• Number of Poles: Three-pole
• Interrupt Rating: 100 kAIC at 240 Vac, 65 kAIC at 480 Vac
• Mounting Type: L-Frame
• Terminal Material: Aluminum
• Terminals: Line and load
• Frequency Rating: 50 to 60 Hz
• Trip Type: T186 (Fixed thermal, fixed magnetic)
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HLDB3600C
• Manufacturer : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HLDB
• Voltage : 600
• Amperage : 600
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : L Frame
• Protection : Thermal Magnetic

Product Data

• Weight : 25
