HLDB3350W - Eaton Series C Molded Case Circuit Breaker 350A 3-Pole L-Frame

HLDB3350W

HLDB3350W is an Eaton Series C molded case circuit breaker designed for industrial and commercial power distribution applications. This complete breaker features a three-pole configuration with 350-ampere rating and fixed thermal/fixed magnetic trip protection for reliable overcurrent and short-circuit protection.Technical Description

The HLDB3350W is a bolt-on molded case circuit breaker with L-frame construction and 600 VAC rated voltage. It delivers interrupt ratings of 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, and 25 kAIC at 600 Vac, making it suitable for demanding electrical systems. The breaker includes a Mil-Spec HI shock 115V shunt trip with 50-inch pigtail leads for remote tripping capability and operates at 50/60 Hz frequency.

Key Specifications

• Part Number: HLDB3350W
• Manufacturer: Eaton
• Amperage Rating: 350 A
• Number of Poles: Three-pole
• Voltage Rating: 600 VAC / 250 VDC
• Frame Type: L-frame
• Trip Type: Fixed Thermal / Fixed Magnetic
• Interrupt Rating: 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, 25 kAIC at 600 Vac
• Shunt Trip: Mil-Spec HI shock 115V with 50 in pigtail leads
• Certification: UL 489
• Frequency: 50/60 Hz
• Mounting: Bolt-on

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HLDB3350W
• Manufacturer : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HLDB
• Voltage : 600
• Amperage : 350
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : L Frame
• Protection : Thermal Magnetic

Product Data

• Weight : 25
