Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HLD3600VW
HLD3600VW is a 600A, 600Vac, 3-pole molded case circuit breaker from Eaton's Series C L-frame lineup with fixed thermal and magnetic trip.This Eaton HLD3600VW circuit breaker features a robust L-frame design, fixed thermal and magnetic trip units, and is rated for 600 amps at 600 volts AC and 250 volts DC. It provides high interrupting capacity with 100 kAIC at 240 Vac and 65 kAIC at 480 Vac, suitable for demanding industrial and commercial power distribution applications. The breaker has aluminum line and load terminals and is UL listed for safety compliance.
- Key Specifications
- Amperage Rating: 600 A
- Voltage Rating: 600 Vac, 250 Vdc
- Number of Poles: Three-pole
- Frame Type: L-frame
- Series: Series C
- Trip Type: Fixed thermal and fixed magnetic
- Interrupt Rating: 100 kAIC at 240 Vac, 65 kAIC at 480 Vac
- Terminal Material: Aluminum
- Frequency Rating: 50/60 Hz
- Certifications: UL Listed
Additional Information
Lugs are not included
Specifications
- Part Number: HLD3600VW
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Voltage : 600
- Amperage : 600
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 78211498433
- GTIN : 00782114984338
- Country of Origin : United States
- Dimensions : 10.75 in x 8.25 in x 4.06 in (Length/Depth x Height x Width)
- Weight : 23
- Certification : UL Listed
