Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HLD3450Y
HLD3450Y is a Series C molded case circuit breaker from Eaton, designed for reliable protection in commercial and industrial applications.This L-frame, three-pole circuit breaker features a fixed thermal and fixed magnetic trip unit, rated for 450 amps and 600 volts AC. It is engineered for high interrupting capacity and is suitable for use in demanding environments. The breaker is UL Listed and compatible with a wide range of accessories for enhanced flexibility.
- Part Number: HLD3450Y
- Manufacturer: Eaton
- Series: Series C
- Frame: L-Frame
- Amperage Rating: 450 A
- Voltage Rating: 600 Vac, 250 Vdc
- Number of Poles: Three-pole
- Interrupt Rating: 100 kAIC at 240 Vac, 65 kAIC at 480 Vac
- Mounting Type: Bolt-On
- Terminal Material: Aluminum
- Frequency Rating: 50/60 Hz
- Certifications: UL Listed
Specifications
- Part Number: HLD3450Y
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HLD
- Voltage : 600
- Amperage : 450
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : L Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 22
