Product Info
- Manufacturer:Westinghouse
- Sub-Category:Trip Units & Programmers
Description
HLA3500T
HLA3500T is a 500 amp, 3-pole molded case circuit breaker trip unit designed for 600V AC applications with UL approval. This robust trip unit is engineered to provide reliable circuit protection in low voltage distribution systems and is compatible with HLA and LA frame breakers. Key Specifications
- Amperage Rating: 500 Amp
- Voltage Rating: 600V AC Maximum
- Poles: 3 Pole
- Interrupting Rating: 35 kAIC at 600V AC, 65 kAIC at 240V AC
- Frame Type: HLA, LA
- Product Type: Trip Unit Only
- Certification: UL Approved
- Manufacturer: Westinghouse
Specifications
- Part Number: HLA3500T
- Manufacturer : Westinghouse
- Brand : Westinghouse
- Category : Circuit Breaker
- Item Subcategory : Trip Units & Programmers
- Family : MARK 75
- Type : HLA
- Voltage : 600
- Poles : 3
- Functions : LI - Long-Time and Instantaneous
- Amperage Maximum : 500
- Amperage Minimum : 500
- Protection : Thermal Magnetic
- Compatible Frames : LA,HLA
Product Data
- UPC : 786679188040
- GTIN : 00786679188040
- Country of Origin : United States
- Dimensions : 5.5 in x 5.5 in x 5.5 in (Length/Depth x Height x Width)
- Weight : 2.6
- Certification : UL Listed
