Product Info
- Manufacturer:Westinghouse
- Sub-Category:Trip Units & Programmers
Description
HLA3350T
HLA3350T is a Westinghouse 350 amp, 600 volt, 3-pole thermal magnetic trip unit designed for MARK 75 series circuit breakers.This trip unit provides long-time and instantaneous (LI) trip functions for reliable overload and short circuit protection. It is interchangeable and compatible with HLA frame molded case circuit breakers, offering bolt-on mounting and load side lug terminals. The unit supports a high interrupting capacity and is part of the MARK 75 family.
- Manufacturer: Westinghouse
- Amperage: 350A
- Voltage: 600V AC
- Poles: 3
- Frame Type: HLA (MARK 75 series)
- Trip Type: Thermal Magnetic with Long-Time and Instantaneous functions
- Mounting Type: Bolt-On
- Interchangeable Trip Unit
- Load Side Lug Terminals
- High Interrupting Capacity (35kAIC @ 480V)
Specifications
- Part Number: HLA3350T
- Manufacturer : Westinghouse
- Brand : Westinghouse
- Category : Circuit Breaker
- Item Subcategory : Trip Units & Programmers
- Family : MARK 75
- Type : HLA
- Voltage : 600
- Poles : 3
- Functions : LI - Long-Time and Instantaneous
- Frame Size : 350
- Amperage Maximum : 350
- Amperage Minimum : 350
- Protection : Thermal Magnetic
- Compatible Frames : LA,HLA
Product Data
- UPC : 786679187128
- GTIN : 00786679187128
- Country of Origin : United States
- Dimensions : 12 in x 5 in x 5 in (Length/Depth x Height x Width)
- Weight : 2
- Certification : UL Listed
