Product Info
- Manufacturer:Westinghouse
- Sub-Category:Molded Case
Description
HLA3300
HLA3300 is a Westinghouse molded case circuit breaker designed for industrial power distribution and circuit protection in low voltage systems. This bolt-on unit features a thermal magnetic trip mechanism with long time and instantaneous trip functions, making it suitable for reliable overcurrent protection in three-phase applications. The breaker is part of the Mark 75 high interrupting capacity series and includes interchangeable trip units for field customization. Key Specifications
- Manufacturer: Westinghouse (Eaton Cutler-Hammer)
- Part Number: HLA3300
- Amperage: 300A
- Voltage: 600VAC
- Poles: 3 Phase
- Frame Type: LA
- Connection: Bolt-On with Load Side Lug Terminals
- Trip Type: Thermal Magnetic with Long Time and Instantaneous Functions
- Interrupt Rating: 35kAIC at 480V
- Series: Mark 75 High Interrupting Capacity
- Trip Unit: Interchangeable
- UL Approved
Specifications
- Part Number: HLA3300
- Manufacturer : Westinghouse
- Brand : Westinghouse
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : MARK 75
- Type : HLA
- Voltage : 600
- Amperage : 300
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- Weight : 29
