HLA3225T - Westinghouse 225A 3 Pole Circuit Breaker Trip Unit 600V HLA Frame

HLA3225T

HLA3225T is a 3 pole circuit breaker trip unit designed for Westinghouse HLA and LA series molded case circuit breakers. This unit provides reliable protection with a rated current of 225 amps and is compatible with 600VAC systems. It features a thermal magnetic trip mechanism with long-time and instantaneous trip functions for effective circuit protection. The HLA3225T trip unit is designed for use in industrial and commercial power distribution applications. It is a direct replacement for obsolete HLA and LA series breakers, offering high interrupting capacity and easy installation. The unit is suitable for bolt-on mounting and is compatible with interchangeable trip systems, making it a versatile solution for various breaker configurations.

• Part Number: HLA3225T
• Manufacturer: Westinghouse
• Rated Current: 225A
• Rated Voltage: 600VAC
• Poles: 3
• Mounting Type: Bolt-On
• Series/Frame: HLA Frame
• Interrupt Rating: 35kA @ 480V
• Trip Unit Type: Thermal Magnetic
• Trip Functions: Long-Time and Instantaneous
• Compatible With: HLA and LA Series Breakers
• Application: Industrial and Commercial Power Distribution

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HLA3225T
• Manufacturer : Westinghouse
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Trip Units & Programmers
• Family : MARK 75
• Type : HLA
• Voltage : 600
• Poles : 3
• Functions : LI - Long-Time and Instantaneous
• Amperage Maximum : 225
• Amperage Minimum : 225
• Protection : Thermal Magnetic
• Compatible Frames : LA,HLA

Product Data

• UPC : 786679185766
• GTIN : 00786679185766
• Country of Origin : United States
• Dimensions : 8.5 in x 4.7 in x 4.7 in (Length/Depth x Height x Width)
• Weight : 2.5
• Certification : UL Listed
