Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HKDB3225
HKDB3225 is a Series C molded case circuit breaker from Eaton designed for industrial and commercial power distribution applications. This 3-pole, 225-amp rated breaker operates at 600 volts AC and 250 volts DC, providing reliable thermal-magnetic protection with fixed trip characteristics. The unit features a K-frame design with feed-thru configuration and sealed construction for enhanced durability in demanding environments.Key Specifications
- Part Number: HKDB3225
- Manufacturer: Eaton Cutler-Hammer
- Type: HKDB
- Series: C
- Poles: 3
- Amperage Rating: 225A
- Voltage Rating: 600 VAC / 250 VDC
- Interrupt Rating: 65kA at 480V
- Trip Unit: Fixed Thermal-Magnetic
- Frame Type: K-Frame
- Connection: Feed-Thru
- Dimensions: 5.5 inches H x 5.5 inches W x 4.1 inches D
- Weight: 11.5 lbs
Specifications
- Part Number: HKDB3225
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HKDB
- Voltage : 600
- Amperage : 225
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : K Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 782113951935
- GTIN : 00782113951935
- Country of Origin : Dominican Republic
- Dimensions : 4.1 in x 5.5 in x 5.5 in (Length/Depth x Height x Width)
- Weight : 11.5
- Certification : UL Listed
