HKDB3100 - Eaton Series C Molded Case Circuit Breaker 3-Pole 100A 600V

HKDB3100

HKDB3100 is a Series C molded case circuit breaker from Eaton designed for three-pole power distribution applications. This K-frame complete breaker features fixed thermal and fixed magnetic trip protection with a 310+ trip unit, suitable for line and load connections in industrial and commercial electrical systems.Technical Specifications: The HKDB3100 delivers 100 amperes at 600 Vac (250 Vdc) with an interrupt rating of 100 kAIC at 240 Vac and 65 kAIC at 480 Vac. The breaker measures 10.13 inches in height, 4.31 inches in length, and 5.5 inches in width, with a net weight of 4.95 kilograms. It is UL Listed and manufactured in the United States.

Key Specifications
• Type: HKDB Series C K-Frame
• Poles: 3-Pole
• Amperage: 100A
• Voltage: 600 Vac, 250 Vdc
• Interrupt Rating: 100 kAIC at 240 Vac, 65 kAIC at 480 Vac
• Trip Unit: Fixed Thermal, Fixed Magnetic 310+
• Terminals: Line and Load
• Frame Type: K-Frame Complete Breaker
• Certification: UL Listed
• Country of Origin: United States
• Height: 10.13 inches (25.73 cm)
• Weight: 4.95 kg (13 lbs)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HKDB3100
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HKDB
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : K Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 782113951881
• GTIN : 00782113951881
• Country of Origin : Dominican Republic
• Dimensions : 4.31 in x 10.13 in x 5.5 in (Length/Depth x Height x Width)
• Weight : 11
• Certification : UL Listed
