HKD3150W - Eaton Series C HKD Molded Case Circuit Breaker 150A 600V 3P Fixed Thermal Magnetic Trip

HKD3150W

HKD3150W is a Series C HKD molded case circuit breaker from Eaton, designed for reliable protection in commercial and industrial power distribution systems. This three-pole breaker features a fixed thermal and fixed magnetic trip unit, providing consistent overcurrent protection for critical circuits. The unit is rated for 150 amps and 600 volts AC, with a high interrupting capacity suitable for demanding applications. Engineered for durability and safety, the HKD3150W is built with a K-frame design and includes feed-thru terminals for easy installation. The non-interchangeable trip unit ensures compatibility and reliability, while the breaker is rated for operation up to 40 degrees Celsius. This molded case circuit breaker is ideal for use in panelboards, switchboards, and other power distribution equipment requiring dependable circuit protection.

• Part Number: HKD3150W
• Manufacturer: Eaton
• Series: Series C
• Type: HKD
• Frame: K-frame
• Amperage: 150 A
• Voltage: 600 VAC
• Poles: 3
• Interrupt Rating: 65 kAIC at 480 VAC
• Mounting Type: Feed-thru
• Thermal Trip: Fixed
• Magnetic Trip: Fixed
• Operating Temperature: 40°C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HKD3150W
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HKD
• Voltage : 600
• Amperage : 150
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : K Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679342800
• GTIN : 00786679342800
• Country of Origin : Dominican Republic
• Dimensions : 4.1 in x 5.5 in x 5.5 in (Length/Depth x Height x Width)
• Weight : 11.5
• Certification : UL Listed
