HKD3100 - Cutler Hammer 100 Amp 3 Pole 600V Molded Case Circuit Breaker, Series C HKD Frame, Thermal Magnetic Trip, Panel Mount, 65kA Interrupt Rating, UL/CSA/CE Certified

HKD3100

HKD3100 is a Cutler Hammer 100 Amp, 3 pole, 600V molded case circuit breaker designed for industrial panel applications.

This Eaton Series C HKD frame breaker features a thermal magnetic trip unit for reliable overload and short-circuit protection, with a 65kA interrupt rating at 480VAC. It is panel-mounted, suitable for three-phase systems, and meets UL, CSA, and CE certifications for safety and compliance.

Key Specifications
• Part Number: HKD3100
• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 100 Amp
• Voltage: 600VAC, 250VDC
• Poles: 3
• Mounting Type: Panel mount
• Interrupt Rating: 100kA @ 240VAC, 65kA @ 480VAC, 35kA @ 600VAC, 22kA @ 250VDC
• Series/Frame: Series C, HKD (K Frame)
• Trip Unit: Thermal magnetic, fixed thermal, fixed magnetic, OPTIM trip unit
• Certifications: UL, CSA, CE
• Terminals: Aluminum/copper, standard pressure line and load
• Dimensions: 10.13" H x 5.5" W x 4.31" D
• Weight: 11.5 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HKD3100
• Manufacturer : Cutler Hammer
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HKD
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Frame Size : K Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679026359
• GTIN : 00786679026359
• Country of Origin : Dominican Republic
• Dimensions : 4.31 in x 10.13 in x 5.5 in (Length/Depth x Height x Width)
• Weight : 11.5
• Certification : UL Listed
