HJXD63B350 - Siemens 350A 600V 3-Pole Molded Case Circuit Breaker JD Frame 35kAIC

HJXD63B350

HJXD63B350 is a Siemens low voltage molded case circuit breaker with a 350 ampere rating and 3 poles designed for reliable power distribution protection.This Siemens Sentron JD frame breaker features a thermal-magnetic trip unit with a high interrupting capacity of 35kA at 600VAC and 65kA at 480VAC. It is rated for 600 VAC/500 VDC operation, has no lugs installed, and meets UL 489 and IEC 60947-2 standards. The breaker is designed for bolt-on mounting and operates at a standard 40 degree Celsius ambient temperature.

Key Specifications
• Amperage: 350 A
• Voltage Rating: 600 VAC / 500 VDC
• Poles: 3
• Interrupt Rating: 35 kA at 600 VAC, 65 kA at 480 VAC
• Frame/Series: JD Frame, Sentron HJXD6
• Trip Unit: Thermal-Magnetic, Non-Interchangeable
• Mounting Type: Bolt-On
• Standards: UL 489, IEC 60947-2
• Operating Temperature: 40°C Standard
• Dimensions (W x H x D): 7.5 x 11 x 4 inches
• No lugs installed
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.




Specifications

• Part Number: HJXD63B350
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : HJXD
• Voltage : 600
• Amperage : 350
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Frame Size : JD Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic



Product Data

• UPC : 783643314917
• GTIN : 00783643314917
• Country of Origin : Mexico
• Weight : 18.301
