HJL36030SN - Square D Powerpact H-Frame 30A 3-Pole 600V Thermal Magnetic Circuit Breaker

HJL36030SN

HJL36030SN is a Square D Powerpact H-Frame molded case circuit breaker designed for reliable protection in commercial and industrial power distribution systems. This 3-pole, 30A, 600V circuit breaker features a thermal magnetic trip unit and is suitable for a wide range of applications requiring robust overcurrent protection. The HJL36030SN is part of the Powerpact H-Frame series and is built with a unit mount lug configuration for easy installation. It provides long-time and instantaneous trip functions, ensuring both overload and short-circuit protection. The breaker is rated for up to 600V AC and 250V DC, with a 65kA interrupt rating at 480V AC and 25kA at 600V AC. It is UL 489 listed and meets multiple international certifications for global acceptance.

• Part Number: HJL36030SN
• Manufacturer: Square D
• Series/Frame: Powerpact H-Frame
• Poles: 3
• Amperage: 30A
• Voltage: 600V AC / 250V DC
• Mounting Type: Unit Mount Lug
• Interrupt Rating: 65kA @ 480V AC, 25kA @ 600V AC
• Protection Type: Thermal Magnetic
• Functions: Long-Time and Instantaneous Trip
• Standards: UL 489 Listed, CSA, NEMA, NMX, VDE, BS, CCC, IEC, CE
• Terminal Type: Lugs Line / Lugs Load

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 12Vdc shunt trip

Specifications

• Part Number: HJL36030SN
• Manufacturer : Square D
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJL
• Voltage : 600
• Amperage : 30
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• Weight : 5
