Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
HJA36125YP
HJA36125YP is a 125 Amp, 600 Volt, 3 Pole I-Line plug-in molded case circuit breaker from Square D's PowerPact H series.This thermal magnetic breaker features a 3-phase design with a 100kA interrupt rating at 240VAC and 65kA at 480VAC, suitable for heavy-duty industrial applications. It includes a plug-in mounting type for easy installation and complies with UL 489 and ANSI C37 standards.
- Manufacturer: Square D
- Part Number: HJA36125YP
- Amperage: 125 Amp
- Voltage Rating: 600/690 VAC, 250 VDC
- Poles: 3 Pole
- Interrupt Rating: 100kA at 240VAC, 65kA at 480VAC
- Mounting Type: I-Line Plug-In
- Series/Frame: PowerPact H
- Trip Unit: Thermal Magnetic
- Certifications: UL 489, ANSI C37
Specifications
- Part Number: HJA36125YP
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Powerpact
- Type : HJA
- Voltage : 600
- Amperage : 20
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : I-Line Style Plug-In
- Functions : LI - Long-Time and Instantaneous
- Temp Rating : 28-158 °F (-2-70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 606486282734
- GTIN : 03606490000000
- Country of Origin : United States
- Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
- Weight : 5
- Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
- Certification : UL, CSA, NOM
- Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
