HHJXD63B350 - Siemens 350 Amp 3-Pole 600V Molded Case Circuit Breaker

HHJXD63B350

HHJXD63B350 is a 3-pole molded case circuit breaker from Siemens designed for industrial power distribution applications requiring high interrupting capacity.

This thermal magnetic circuit breaker features a JD-frame design with non-interchangeable trip unit construction. The breaker delivers reliable overcurrent protection in 600VAC systems and is rated for 350 amperes at 600 volts with 50 kAIC breaking capacity at that voltage. It also provides 100 kAIC at 480 volts, making it suitable for diverse electrical configurations. The unit measures 7.50 inches wide by 11.0 inches high by 4.00 inches deep.

• Amperage Rating: 350 Amps
• Poles: 3
• Voltage: 600VAC
• Frame Size: JD (400 Amp Frame)
• Interrupting Capacity: 50 kAIC @ 600V, 100 kAIC @ 480V
• Trip Unit: Non-Interchangeable Thermal Magnetic
• Series: Sentron HHJXD6
• Dimensions: 7.50 W x 11.0 H x 4.00 D inches
• Weight: 22 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: HHJXD63B350
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : HHJXD
• Voltage : 600
• Amperage : 350
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : JD Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 783643257849
• GTIN : 00783643257849
• Country of Origin : Mexico
• Weight : 20
