HGL26080 - Square D 80A 600V 2 Pole Thermal Magnetic Circuit Breaker PowerPact H Frame

HGL26080

HGL26080 is a Square D 2 pole, 80 amp, 600 volt thermal magnetic circuit breaker from the PowerPact H Frame series.This molded case circuit breaker features a 35kA interrupt rating at 480V, suitable for single-phase applications with line and load lug terminals. It includes long-time and instantaneous trip functions and is UL 489 listed for safety and reliability. The breaker is free standing and designed for unit mount installation.

Key Specifications
• Amperage: 80A
• Voltage Rating: 600V AC, 500V DC
• Number of Poles: 2
• Interrupt Rating: 35kA @ 480V
• Trip Type: Thermal Magnetic with Long-Time and Instantaneous
• Mounting Type: Unit Mount, Free Standing
• Series/Frame: PowerPact H Frame
• Terminal Connection: Line and Load Lug
• Phase: Single Phase
• UL Listed (UL 489)
• Dimensions (HxWxD): Approx. 3.39 x 4.09 x 6.42 inches
• Country of Origin: USA
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: HGL26080
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HGL
• Voltage : 600
• Amperage : 80
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous
• Terminal Connection : Line/Load Lug
• Frame Size : 150A/HG
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 3 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : Not Applicable



Product Data

• UPC : 785901433873
• GTIN : 00785901433873
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.04
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
