HGA36150AA - Square D 150A 600V 3 Pole PowerPact H Circuit Breaker I-Line Plug-In

HGA36150AA

HGA36150AA is a 150 Amp, 600 Volt, 3 Pole PowerPact H molded case circuit breaker by Square D designed for industrial and commercial power distribution.This thermal magnetic breaker features an I-Line style plug-in connection, long-time and instantaneous trip functions (LI), and a high interrupting rating of 35kA at 480VAC. It is UL, CSA, CE, NOM, IEC, and NEMA certified, suitable for use in harsh environments with a temperature rating from -25 to 70 °C. The breaker supports ABC phase connection and load side lug terminals, compatible with wire gauges AWG 14 to 3/0 aluminum or copper.

• Amperage: 150A
• Voltage Rating: 600/690VAC
• Poles: 3
• Series/Frame: PowerPact H, HGA Frame
• Interrupting Rating: 35kA at 480VAC
• Mounting Type: I-Line Style Plug-In
• Trip Unit: Thermal Magnetic with Long-Time and Instantaneous (LI) functions
• Certifications: UL, CSA, CE, NOM, IEC, NEMA
• Terminal Connection: Load Side Lug
• Phase Connection: ABC
• Operating Temperature: -25 to 70 °C
• Auxiliary Switch: Included (1A1B)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HGA36150AA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 600
• Amperage : 150
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
