Description
HFDE316035L
HFDE316035L is a 160 amp, 600 volt, 3-pole Series C electronic molded case circuit breaker from Eaton with an F-frame and Digitrip 310 RMS electronic LSG trip unit.This Eaton HFDE316035L breaker features a 65kA interrupt rating at 480 VAC and 100kA at 240 VAC, suitable for feed-thru applications. It supports 600 VAC and 250 VDC maximum voltages, with electronic long-time, short-time, and ground fault trip protection. The breaker is UL listed and designed for reliable industrial and commercial power distribution.
- Key Specifications
- Amperage: 160 A
- Voltage Rating: 600 VAC / 250 VDC
- Number of Poles: 3
- Frame Type: F-Frame (FDE)
- Series: C
- Trip Unit: Digitrip 310 RMS Electronic LSG
- Interrupt Rating: 65kA @ 480 VAC, 100kA @ 240 VAC
- Mounting Type: Feed-Thru
- Certifications: UL Listed
- Part Number: HFDE316035L
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HFDE
- Voltage : 480 AC
- Amperage : 160
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LS - Long-Time and Short-Time
- Frame Size : F Frame
- Protection : Solid State
- UPC : 786685112640
- GTIN : 00786685112640
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 4.4
- Certification : UL Listed
