Product Info
- Manufacturer:Westinghouse
- Sub-Category:Molded Case
Description
HFDE316032L
HFDE316032L is a 3-pole molded case circuit breaker from Westinghouse with FDE frame and electronic LSI trip unit.This FDE frame breaker features solid state protection with long time, short time, and instantaneous trip functions, feed-thru mounting, and line and load side lug terminals for high interrupting capacity applications.
- Part Number: HFDE316032L
- Manufacturer: Westinghouse
- Amperage: 160A
- Voltage: 600VAC
- Poles: 3
- Frame: FDE
- Trip Unit: Electronic LSI
- Mounting: Feed-Thru
- Interrupt Rating: 65kAIC at 480V
- Protection: Solid State
Specifications
- Part Number: HFDE316032L
- Manufacturer : Westinghouse
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HFDE
- Voltage : 480 AC
- Amperage : 160
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LSI - Long-Time, Short-Time and Instantaneous
- Frame Size : F Frame
- Protection : Solid State
Product Data
- UPC : 786685112558
- GTIN : 00786685112558
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 4.13 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
