Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HFDDC3125L
HFDDC3125L is a 3-pole, 125 amp, 600 volt thermal magnetic molded case circuit breaker from Eaton's HFDDC series with F frame.This Eaton HFDDC3125L features thermal magnetic trip unit, line and load side lug terminals, DC rated design, and high interrupting capacity for reliable circuit protection in industrial applications.
- Part Number: HFDDC3125L
- Manufacturer: Eaton
- Amperage: 125A
- Voltage: 600VAC / 250VDC
- Poles: 3
- Series/Frame: HFDDC / F Frame
- Trip Unit: Thermal Magnetic
- Interrupt Rating: 42kA at 600VDC
- Mounting Type: Panel Mount
- Certifications: UL 489, CSA C22.2
Specifications
- Part Number: HFDDC3125L
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HFDDC
- Voltage : 628 DC
- Amperage : 125
- Phase : 3
- Poles : 3
- AIC rating : 42kA@600V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 621037112193
- GTIN : 00621037112193
- Country of Origin : United States
- Dimensions : 3.38 in x 4.13 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 4.5
