HFD2225 - Cutler Hammer 225A 600VAC 2-Pole Molded Case Circuit Breaker, Series C, Thermal Magnetic Trip

HFD2225

HFD2225 is an Eaton Series C molded case circuit breaker designed for industrial power distribution applications requiring reliable thermal magnetic protection. This F-frame breaker delivers high interrupting capacity with a 65kA rating at 480VAC, making it suitable for demanding electrical systems.HFD2225 features a 225-ampere rating at 600VAC (250VDC), two-pole configuration, and bolt-on connection for panel mounting. The breaker employs thermal magnetic trip technology with long-time and instantaneous functions to protect circuits from overloads and short circuits. It is UL, CSA, and CE certified for use in industrial environments operating at 50/60 Hz.

• Amperage Rating: 225A
• Voltage: 600VAC / 250VDC
• Poles: 2
• Frame Type: Series C, F-Frame
• Trip Type: Thermal Magnetic
• Interrupting Rating: 65kA @ 480VAC
• Connection: Bolt-On
• Phase: Single Phase
• Certifications: UL, CSA, CE
• Dimensions: 2.75" H x 2.75" W x 3.38" D
• Weight: 4.5 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HFD2225
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HFD
• Voltage : 600 AC
• Amperage : 225
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679015315
• GTIN : 00786679015315
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 2.75 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
