HED43B100 - Siemens 100A 480V 3 Pole Bolt-On Molded Case Circuit Breaker ED Frame

HED43B100

HED43B100 is a Siemens 3 pole, 100 amp, 480 volt bolt-on molded case circuit breaker designed for reliable thermal magnetic protection.This Siemens Sentron Series HED type breaker features a 42kA interrupting rating at 480V, ED frame rated for 40°C, and includes long-time and instantaneous trip units. It is UL 489 and CSA 22.2 listed, suitable for three-phase applications with bolt-on mounting and load side lug terminals.

• Amperage: 100A
• Voltage: 480V AC
• Poles: 3
• Phase: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 42kA at 480V
• Series/Frame: Sentron HED, ED Frame
• Trip Unit: Thermal Magnetic (Long-Time and Instantaneous)
• Certifications: UL 489, CSA 22.2 Listed
• Dimensions: Approx. 6.35" x 3.0" x 4.56"
• Weight: 0.34 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HED43B100
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : HED
• Voltage : 480
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 42kA@480V
• Connection : Lug In Panelboard
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Load Side Lug
• Frame Size : 125A/ED
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 10 AWG
• Breaker Type : High Interrupting Capacity
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 783643210219
• GTIN : 00783643210219
• Country of Origin : Mexico
• Dimensions : 3 in x 6.34 in
• Weight : 0.328
• Panel Type : SB Switchboards, Sentron Panelboards
• Standards : HACR Rated, UL Listed
• Certification : HACR Rated, UL Listed
• Wire Size : AWG 10 to AWG 1/0, Cu/Al
