HDM36080 - Square D 80 Amp 600 Volt 3 Pole H-Frame Molded Case Circuit Breaker Thermal Magnetic

HDM36080

HDM36080 is a Square D 80 Amp, 600 Volt, 3 Pole molded case circuit breaker with thermal magnetic trip unit and H-Frame design.

This circuit breaker features a bolt-on mounting type and provides reliable thermal magnetic protection with long-time and instantaneous trip functions. It is rated for 80 amps continuous current and supports up to 600 volts. The breaker has an 18kA interrupt rating at 480 volts and is UL 489 listed, ensuring compliance with safety standards. Designed for use in PowerPact H series applications, it offers robust performance for industrial and commercial electrical distribution.

Key Specifications
• Amperage: 80 Amp
• Voltage: 600 Volt
• Poles: 3
• Frame Type: H-Frame
• Mounting Type: Bolt-On
• Interrupt Rating: 18kA at 480V
• Trip Unit: Thermal Magnetic with Long-Time and Instantaneous
• Standards: UL 489 Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDM36080
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDM
• Voltage : 600
• Amperage : 80
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Protection : Thermal Magnetic

Product Data

• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.9
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
