HDM36070 - Square D PowerPacT H 70A 3 Pole 600VAC 14kA Thermal Magnetic Circuit Breaker

HDM36070

HDM36070 is a Square D PowerPacT H-frame molded case circuit breaker designed for reliable protection in industrial and commercial power distribution systems. This 3-pole breaker features a 70A current rating, 600VAC maximum voltage, and a 14kA interrupt rating, making it suitable for demanding applications. The HDM36070 utilizes a thermal-magnetic trip unit for precise overload and short-circuit protection. It is equipped with lug terminals for secure connections and is designed for unit mount installation. The breaker is part of the PowerPacT H series, known for durability and performance in heavy-duty environments.

• Part Number: HDM36070
• Manufacturer: Square D
• Series/Frame: PowerPacT H
• Amperage: 70A
• Number of Poles: 3
• Maximum Voltage: 600VAC
• Interrupt Rating: 14kA
• Mounting Type: Unit Mount
• Terminal Connection: Lug
• Tripping Mechanism: Thermal-Magnetic
• Circuit Breaker Type: Molded Case
• Color: Black

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDM36070
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDM
• Voltage : 600
• Amperage : 70
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug, Terminal Nut
• Frame Size : H
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Thermal Magnetic

Product Data

• UPC : 606486119160
• GTIN : 03606486119167
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
