Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
GI2070
GI2070 is a 70 Amp, 2 Pole molded case circuit breaker from Cutler Hammer designed for reliable circuit protection in industrial and commercial applications.GI2070 features thermal magnetic trip protection with a 480VAC voltage rating and Series C frame, suitable for bolt-on mounting. It offers a 14kA interrupting rating at 480Y/277VAC and 65kA at 240VAC, meeting UL and CSA certifications for safety and performance.
- Amperage: 70A
- Voltage Rating: 480Y/277VAC, 125/250VDC
- Poles: 2
- Series/Frame: C (GHB frame type)
- Mounting Type: Bolt-On
- Interrupting Rating: 14kAIC at 480Y/277VAC, 65kAIC at 240VAC
- Trip Unit: Thermal Magnetic (Long-Time and Instantaneous Trip)
- Certifications: UL, CSA
- Connection Type: Bolt-On
- Phase: 1
- Temperature Rating: 40 °C
Specifications
- Part Number: GI2070
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Universal
- Type : GI
- Voltage : 480
- Amperage : 70
- Phase : 1
- Poles : 2
- AIC rating : 14kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 786679376881
- GTIN : 00786679376881
- Country of Origin : Dominican Republic
- Dimensions : 2.63 in x 4.88 in x 2 in (Length/Depth x Height x Width)
- Weight : 1.45
- Certification : UL Listed
