Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
GHQRD1020
GHQRD1020 is a 1 pole, 20 amp thermal magnetic circuit breaker from Eaton Cutler Hammer designed for remote operation in power distribution systems.This Eaton GHQRD1020 circuit breaker features a 20 ampere rating, 277/480 VAC voltage rating, and a 14 kA interrupt rating at 277V. It is a single-pole, bolt-on mounted breaker with a thermal magnetic trip unit and solenoid-operated remote trip capability. The breaker is part of the GHQR series/frame and includes line side lug terminals. It operates at 50/60 Hz and is designed for non-interchangeable trip applications.
- Key Specifications
- Manufacturer: Eaton Cutler Hammer
- Part Number: GHQRD1020
- Amperage: 20 Amps
- Voltage: 277/480 VAC
- Poles: 1
- Interrupt Rating: 14 kA at 277V
- Mounting Type: Bolt-On
- Trip Unit: Thermal Magnetic with Solenoid Remote Operation
- Series/Frame: GHQR
- Frequency: 50/60 Hz
- Terminal Type: Line Side Lug
- Trip Type: Non-Interchangeable
- Part Number: GHQRD1020
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Type : GHQ
- Voltage : 277/480VAC
- Amperage : 20
- Phase : 1
- Poles : 1
- AIC rating : 14kAIC at 277VAC, 65kAIC at 120/240VAC
- Connection : Bolt-On
- Functions : Non-Interchangeable Trip
- Protection : Thermal Magnetic
- Compatible Frames : GHQR
- UPC : 786685703480
- GTIN : 00786686000000
- Country of Origin : Dominican Republic
- Dimensions : 6.25 in x 1.25 in x 3.25 in (Length/Depth x Height x Width)
- Weight : 0.72
- Certification : UL, CSA
