GHC3040 - Cutler Hammer 3 Pole 40A 480Y/277VAC Molded Case Circuit Breaker

GHC3040

GHC3040 is a 3 pole, 40 amp molded case circuit breaker designed for reliable protection in commercial and industrial power distribution systems.This Cutler Hammer Series C NEMA G-frame circuit breaker features a fixed thermal-magnetic trip unit and is rated for 480Y/277VAC and 125/250VDC applications. The breaker is designed for cable-in/cable-out (feed-thru) mounting, making it suitable for a wide range of panelboard and switchgear installations.

• Part Number: GHC3040
• Manufacturer: Cutler Hammer
• Series/Frame: Series C, G-frame
• Poles: 3
• Amperage: 40A
• Voltage: 480Y/277VAC, 125/250VDC
• Mounting Type: Cable-in/cable-out (feed-thru)
• Interrupt Rating: 14kAIC
• Trip Unit: Fixed thermal-magnetic
• Connection Type: Feed-thru

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: GHC3040
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : GHC
• Voltage : 480
• Amperage : 40
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Frame Size : G Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679174241
• GTIN : 00786679174241
• Country of Origin : Dominican Republic
• Dimensions : 2.63 in x 4.88 in x 3 in (Length/Depth x Height x Width)
• Weight : 1.7
• Certification : UL Listed
• Wire Size : 10 to 1/0 AWG
