GHB1015 - Cutler Hammer 15 Amp 1 Pole 277VAC Bolt-On Molded Case Circuit Breaker, G Frame, Thermal Magnetic Trip, UL/CSA Certified

GHB1015

GHB1015 is a Cutler Hammer single-pole molded case circuit breaker designed for reliable circuit protection in commercial and industrial applications.

This thermal magnetic circuit breaker features a 15 Amp current rating, 277VAC/125VDC voltage rating, and is part of the G Frame series with a bolt-on mounting type for secure panelboard installation. It offers a 14kAIC interrupting rating at 277VAC, ensuring robust protection against short circuits. The GHB1015 is UL and CSA certified for safety and compliance, and is HACR rated for heating, air conditioning, and refrigeration equipment.

Key Specifications
• Part Number: GHB1015
• Manufacturer: Cutler Hammer
• Amperage: 15A
• Voltage: 277VAC, 125VDC
• Poles: 1
• Mounting Type: Bolt-On
• Interrupt Rating: 14kAIC at 277VAC
• Series/Frame: G Frame (GHB)
• Trip Unit: Thermal Magnetic (Long-Time & Instantaneous)
• Certifications: UL, CSA, HACR
• Connection: Screw Clamp Terminal
• Frequency Rating: 50/60 Hz
• Temperature Rating: 40¡C

Specifications

• Part Number: GHB1015
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : GHB
• Voltage : 480
• Amperage : 15
• Phase : 1
• Poles : 1
• AIC rating : 14kA@277V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Screw Clamp
• Frame Size : 100/GHB
• Temp Rating : 28-158 ¡F (-2-70 ¡C)
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 10 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic

Product Data

• UPC : 786679023617
• GTIN : 00786679023617
• Country of Origin : Dominican Republic
• Dimensions : 2.63 in x 4 in x 1 in (Length/Depth x Height x Width)
• Weight : 0.7
• Panel Type : Eaton Powerline Panelboards
• Standards : UL 489
• Certification : CSA Certified, UL Listed
