Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
FXD62S250A
FXD62S250A is a Siemens 250 amp, 600 volt AC, 2-pole molded case circuit breaker with a thermal magnetic trip unit designed for industrial power distribution.This breaker is built on the FXD6 frame and features a bolt-on mounting style. It has a 65kA interrupting capacity at 480V, suitable for panelboards, switchboards, and OEM control panels. The unit includes a factory or field-installed low voltage switch accessory for enhanced protection and remote switching capabilities. It meets UL 489 and ANSI certification standards.
- Brand: Siemens
- Part Number: FXD62S250A
- Amperage: 250A
- Voltage Rating: 600V AC
- Poles: 2
- Interrupting Capacity: 65kA at 480V
- Trip Unit: Thermal Magnetic
- Frame Type: FXD6
- Mounting Style: Bolt-On
- Accessory: Low Voltage Switch
- Certifications: UL 489, ANSI
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
Specifications
- Part Number: FXD62S250A
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : FXD
- Voltage : 600
- Amperage : 250
- Phase : 1
- Poles : 2
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : NA - No Overcurrent
- Frame Size : FD Frame
- Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
- Protection : Non-Automatic
Product Data
- UPC : 783643212350
- GTIN : 00783643212350
- Country of Origin : Mexico
- Weight : 7
- Certification : UL, CSA, IEC
