FH36090 - Square D 90 Amp 600VAC 3 Pole I-Line Molded Case Circuit Breaker, 25kAIC Interrupt Rating

FH36090

FH36090 is a Square D 3 Pole molded case circuit breaker rated for 90 Amps and 600VAC with I-Line plug-in mounting.This thermal magnetic circuit breaker features a 25kA interrupting rating at 480V, long-time and instantaneous trip functions (LI), and is designed for use in industrial and commercial power distribution. It complies with UL, CSA, and CE certifications and is built on the FH frame series with load side lug terminals.

Key Specifications
• Amperage: 90 Amps
• Voltage Rating: 600VAC
• Poles: 3
• Mounting Type: I-Line plug-in
• Interrupting Rating: 25kAIC at 480V
• Frame Type: FH
• Trip Unit: Thermal Magnetic with LI (long-time and instantaneous)
• Certifications: UL, CSA, CE
• Connection Type: Load side lug
• Dimensions: 4.5" W x 4.13" D x 6.4" H
• Temperature Rating: 40°C
• Standards: HACR
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: FH36090
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : FH
• Voltage : 600
• Amperage : 90
• Phase : 3
• Poles : 3
• AIC rating : 25kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic



Product Data

• UPC : 785901241393
• GTIN : 00785901241393
• Country of Origin : Mexico
• Dimensions : 6.4 in (162.6 mm) x 4.5 in (114.3 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
• Weight : 6
