Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Panel Mount
Description
FDPW366MJ
FDPW366MJ is a Cutler Hammer 600A 600V 3 pole fusible panel mount switch designed for reliable main disconnect applications in industrial and commercial power distribution systems.This fusible panelboard switch is part of the FDPW series and is rated for 600 volts AC, 600 amperes, and features a horizontal main mounting configuration. It is compatible with Class J fuses and is engineered for use in panelboards with a NEMA 1 enclosure rating. The switch provides a maximum interrupting capacity of 200,000A rms symmetrical at 600V AC, ensuring robust protection in demanding environments.
- 600A Amperage
- 600V AC Voltage
- 3 Pole
- 3 Phase
- Fusible Switch Type
- Panel Mount (Horizontal Main)
- Class J Fuse Compatible
- 200,000A Interrupting Capacity
- NEMA 1 Enclosure Rating
- Series: FDPW
- 200 hp at 240V AC
- 400 hp at 480V AC
- 500 hp at 600V AC
Specifications
- Part Number: FDPW366MJ
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Switch
- Item Subcategory : Panel Mount
- Family : Type FDP
- Type : FDPW
- Voltage : 600
- Amperage : 600
- Phase : 3
- Poles : 3
- AIC rating : 200kA@480V
- Fuse Class : J
- Configuration : Single
- Switch Style : Fusible
- Nema Rating : 1
- Compatible Frames : TFJ
Product Data
- UPC : 786679783962
- GTIN : 00786679783962
- Country of Origin : Mexico
- Dimensions : 24.5 in x 10 in x 16.3 in (Length/Depth x Height x Width)
- Weight : 52
- Certification : UL Listed
