FDPBS364JDS - Cutler Hammer 200A 3-Pole 600V Fusible Panelboard Switch with Shunt Trip

FDPBS364JDS

FDPBS364JDS is a Cutler Hammer fusible panelboard switch designed for reliable circuit protection in industrial and commercial applications. This 3-pole, 200A switch is rated for 600V and features a Type FDPBS frame for secure mounting and operation. The unit is equipped with a shunt trip for remote disconnect capability and is compatible with Class J fuses for added safety and flexibility. The switch is built for horizontal mounting and includes pressure terminals for secure wire connections.Engineered for durability and performance, the FDPBS364JDS is ideal for use in panelboards requiring a fusible disconnect with high interrupt capacity. The switch provides robust protection for branch circuits and is suitable for a wide range of electrical distribution systems.

• 200A amperage rating
• 600V voltage rating
• 3-pole configuration
• Horizontal mounting
• 200 kAIC interrupt rating
• Type FDPBS frame
• Shunt trip feature
• Class J fuse compatibility
• Pressure terminals supplied
• Branch connection type
• Maximum horsepower: 60 hp @ 240V, 125 hp @ 480V, 150 hp @ 600V
• Dimensions: 22" L x 9.5" W x 10" H

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FDPBS364JDS
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Switch
• Item Subcategory : Panel Mount
• Family : Type FDP
• Type : FDPBS
• Voltage : 600
• Amperage : 200
• Phase : 3
• Poles : 3
• AIC rating : 200kA@240V
• Breaker Type : FD
• Configuration : Single
• Switch Style : Breaker Type
• Nema Rating : 1
• Compatible Frames : FD

Product Data

• UPC : 782114895221
• GTIN : 00782114895221
• Country of Origin : Mexico
• Dimensions : 22 in x 10 in x 9.5 in (Length/Depth x Height x Width)
• Weight : 23
• Certification : UL Listed
