Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
FDC4030L
FDC4030L is an Eaton Cutler-Hammer Series C molded case circuit breaker designed for industrial and commercial power distribution applications requiring reliable thermal-magnetic protection. This four-pole breaker delivers 30-ampere rated current at 600 volts AC, making it suitable for three-phase systems up to 600 VAC and 250 VDC operation. The F-frame design provides compact mounting in standard electrical enclosures with thermal-magnetic trip characteristics for dependable overcurrent and short-circuit protection. Key Specifications
- Part Number: FDC4030L
- Manufacturer: Eaton Cutler-Hammer
- Series: C (F-Frame)
- Poles: 4
- Amperage: 30A
- Voltage Rating: 600 VAC / 250 VDC
- Frequency: 50/60 Hz
- Trip Type: Thermal-Magnetic
- Dimensions: 5.5 inches W x 3.375 inches D x 6 inches H
- Breaker Type: Molded Case
Specifications
- Part Number: FDC4030L
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : FDC
- Voltage : 600
- Amperage : 30
- Phase : 3
- Poles : 4
- AIC rating : 100kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679271537
- GTIN : 00786679271537
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 5.5 in (Length/Depth x Height x Width)
- Weight : 6
- Certification : UL Listed
