FDB2090L - Eaton 90A 600V 2-Pole Molded Case Circuit Breaker Series C F-Frame

FDB2090L

FDB2090L is a 2-pole, 90 amp molded case circuit breaker from Eaton's Series C F-frame lineup designed for reliable circuit protection.This Eaton FDB type breaker supports 600 VAC and 250 VDC voltage ratings with a fixed thermal and magnetic trip unit (T186). It features a 14 kA interrupt rating at 480 VAC and is suitable for line and load connections. The breaker is designed for industrial and commercial applications requiring robust and durable circuit interruption.

Key Specifications
• Amperage: 90 A
• Voltage Rating: 600 VAC / 250 VDC
• Poles: 2
• Interrupt Rating: 14 kA at 480 VAC
• Series/Frame: Series C, F-Frame
• Trip Unit: Fixed thermal and magnetic (T186)
• Connection Type: Line and Load
• Type: FDB Molded Case Circuit Breaker
• Mounting: Standard molded case breaker mounting
• Certifications: NETA tested (when applicable)
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: FDB2090L
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FDB
• Voltage : 600
• Amperage : 90
• Phase : 1
• Poles : 2
• AIC rating : 14kA@600V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic



Product Data

• UPC : 786679850824
• GTIN : 00786679850824
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL Listed
