FDB2090 - Cutler Hammer 90A 2 Pole 600VAC Molded Case Circuit Breaker Series C F-Frame Thermal Magnetic Fixed Trip

FDB2090

FDB2090 is a Cutler Hammer Series C molded case circuit breaker designed for reliable electrical protection in industrial and commercial applications.This 2 pole, 90 ampere, 600VAC circuit breaker features a thermal magnetic fixed trip unit, F-frame construction, and is rated for 14kA interrupting capacity at 600VAC. It is panel mountable and includes feed-thru terminals for ease of installation. The breaker is suitable for use in a wide range of power distribution systems and meets UL and CSA safety standards.

• Part Number: FDB2090
• Manufacturer: Cutler Hammer
• Series: Series C
• Frame: F-Frame
• Poles: 2 Pole
• Amperage: 90A
• Voltage: 600VAC, 250VDC
• Interrupt Rating: 14kA @ 600VAC
• Mounting Type: Panel Mount
• Terminal Type: Feed-Thru
• Trip Unit: Thermal Magnetic, Fixed Trip
• Certifications: UL, CSA

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FDB2090
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FDB
• Voltage : 600
• Amperage : 90
• Phase : 1
• Poles : 2
• AIC rating : 14kA@600V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679312452
• GTIN : 00786679312452
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL Listed
