FDB2010 - Cutler Hammer 10A 600V 2 Pole Molded Case Circuit Breaker F Frame Thermal Magnetic

FDB2010

FDB2010 is a Cutler Hammer 2 pole molded case circuit breaker rated for 10 amps and 600 volts AC, designed for reliable circuit protection.This Eaton Series C F-frame breaker features a fixed thermal and magnetic trip unit, suitable for 50/60 Hz applications with a 14kA interrupt rating at 600V AC. It supports 250 VDC and offers UL certification for safety compliance. The breaker is bolt-on mounted and designed for industrial and commercial electrical distribution systems.

• Amperage: 10 A
• Voltage Rating: 600 VAC, 250 VDC
• Poles: 2
• Frame Type: F Frame
• Trip Type: Fixed Thermal Magnetic
• Interrupt Rating: 14 kA at 600 VAC
• Mounting Type: Bolt-On
• Frequency: 50/60 Hz
• Certification: UL Listed
• Dimensions (HxWxD): 6 x 2.75 x 3.38 inches
• Weight: 3 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FDB2010
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FDB
• Voltage : 600
• Amperage : 10
• Phase : 1
• Poles : 2
• AIC rating : 14kA@600V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679399422
• GTIN : 00786679399422
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL Listed
