FD4100E - Eaton 100A 4-Pole Molded Case Circuit Breaker Series C 600V F-Frame Fixed Thermal Magnetic Trip

FD4100E

FD4100E is a Series C molded case circuit breaker designed for reliable electrical protection in commercial and industrial applications. This Eaton FD4100E breaker features a 4-pole configuration, 100A current rating, and 600 Vac voltage rating, making it suitable for a wide range of power distribution needs. The FD4100E is built with a fixed thermal and fixed magnetic trip unit, providing dependable overcurrent protection. It is constructed in an F-frame for compatibility with standard enclosures and mounting systems. The breaker is rated for 65 kAIC at 240VAC, 35 kAIC at 480VAC, and 18 kAIC at 600VAC, ensuring robust performance in demanding environments.

• Part Number: FD4100E
• Manufacturer: Eaton
• Series: Series C
• Frame: F-Frame
• Poles: 4-Pole
• Amperage Rating: 100A
• Voltage Rating: 600 Vac, 250 Vdc
• Interrupt Rating: 65 kAIC @ 240VAC, 35 kAIC @ 480VAC, 18 kAIC @ 600VAC
• Mounting Type: Standard F-Frame Mounting
• Breaker Type: Molded Case Circuit Breaker
• Series/Frame: Series C, F-Frame
• Mounting Type: Standard F-Frame Mounting
• Trip Unit: Fixed Thermal, Fixed Magnetic

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FD4100E
• Manufacturer : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FD
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 4
• AIC rating : 25kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 78667924932
• GTIN : 00786679249321
• Country of Origin : United States
• Dimensions : 3.38 in x 6 in x 5.5 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
