FD3150L - Cutler Hammer 150 Amp 600V 3-Pole Molded Case Circuit Breaker, Series C, F Frame, Thermal Magnetic Trip, 35kA@480V Interrupt Rating

FD3150L

FD3150L is a Cutler Hammer molded case circuit breaker designed for reliable protection in commercial and industrial power distribution systems.

This 3-pole, 150 amp breaker features a 600V AC/250V DC rating, F frame, and thermal magnetic trip unit with long-time and instantaneous protection. It is part of the Series C family and offers a 35kA interrupting capacity at 480V, making it suitable for demanding applications where high fault current protection is required. The FD3150L includes line and load side lug terminals and is rated for operation at up to 40°C ambient temperature.

Key Specifications
• Part Number: FD3150L
• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 150A
• Voltage: 600V AC, 250V DC
• Poles: 3
• Mounting Type: Molded Case
• Interrupt Rating: 35kA @ 480V AC
• Series/Frame: Series C, F Frame
• Trip Unit: Thermal Magnetic (LI - Long-Time and Instantaneous)
• Connection: Feed-Thru
• Certifications: Standard industrial certifications (exact certifications not specified in available data)
• Dimensions: 6" x 4.13" x 3.38"
• Weight: 4.35 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FD3150L
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FD
• Voltage : 600
• Amperage : 150
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679305805
• GTIN : 00786679305805
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
