FD3045L - Cutler Hammer 45A 3P 600V Molded Case Circuit Breaker FD Frame Thermal Magnetic Trip

FD3045L

FD3045L is a molded case circuit breaker from Cutler Hammer, designed for reliable protection in industrial and commercial power distribution systems. This breaker features a fixed thermal and fixed magnetic trip unit for dependable overcurrent protection. The FD3045L is a three-pole, 45 ampere circuit breaker rated for 600 volts AC. It is part of the FD frame Series C and is built for feed-thru mounting. The breaker is rated for a standard interrupting capacity of 18kA at 600V and 35kA at 480V, making it suitable for a wide range of applications. It operates at a maximum ambient temperature of 40 degrees Celsius and is designed for use in three-phase systems.

• Part Number: FD3045L
• Manufacturer: Cutler Hammer
• Amperage: 45A
• Voltage: 600V AC
• Poles: 3
• Mounting Type: Feed-Thru
• Interrupt Rating: 18kA @ 600V, 35kA @ 480V
• Series/Frame: FD Frame, Series C
• Phase: 3-Phase
• Trip Unit: Fixed Thermal, Fixed Magnetic
• Operating Temperature: 40°C
• Application: Molded Case Circuit Breaker

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FD3045L
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FD
• Voltage : 600
• Amperage : 45
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679451748
• GTIN : 00786679451748
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
